The body steel plate of the cheap beiben 8x4 dump trucks for sale is integrally stamped and formed, the composite sandwich steel plate is welded together, and the Beiben cab with an all-steel skeleton and double cavities has three safety lines of defense, which effectively improves passive safety, has higher structural strength, and reduces the absorption of the cab. Energy, vibration and deformation, better soundproofing effect, the beiben 8x4 dump trucks for sale protect the life safety of drivers
This cheap beiben 8x4 dump trucks for sale takes advantage of the technical advantages of Mercedes-Benz heavy-duty vehicles in Germany, relies on first-class manufacturing equipment and technological processes, deepens cooperation with powerful parts suppliers such as Weichai and Fast, and optimizes its own engines, transmissions, axles, cabs, Frame and other important assembly resources.
Cheap Beiben 8x4 Dump Trucks for Sale Near Me in Jamaica
Cheap Beiben 8x4 Dump Trucks for Sale Near Me in Jamaica
Cheap Beiben 8x4 Dump Trucks for Sale Near Me in Jamaica
Name: Beiben 8x4 Dump Trucks for Sale
Drive form: 8X4
Wheelbase: 1950+3400+1450mm
Overall Dimension (mm): 10205x2550x3484
Front track: 2042/2042mm
Rear Track: 1878/1878mm
Vehicle weight: 14.77 tons
Rated load: 16.1 tons
Total mass: 31 tons
Approach angle: 17 degrees
Departure angle: 25 degrees
Engine:
Engine model: Weichai WP10.350E53
Number of cylinders: 6
Fuel Type: Diesel
Displacement: 9.726L
Maximum output power: 257kW
Maximum torque: 1600N m
Maximum torque speed: 1200-1600rpm
Rated speed: 1900rpm
Engine form: Electronically controlled high pressure common rail + SCR
Cargo box
L*W*H (mm): 7200x2350x1180
Cargo box form: self-unloading
Transmission
Gearbox model: Fast 12JS160T
Forward gear: 12th gear
Number of reverse gears: 2
Fuel tank
Fuel tank capacity: Chassis parameters
Frame size:
Rear axle description: 457 single reduction axle
Rear axle allowable load: 18000 (two axles) kg
Speed ratio: 4.769
Number of leaf springs: 12/12/13
Tire
Tire specification: 11.00R20 18PR
Number of tires: 12
