The Beiben v3 12 wheel tipper truck price rear axle is a 13-ton double-link wheel-side reduction axle using Mercedes-Benz technology. At the same time, with Mercedes-Benz technology, the power chain matching of the whole vehicle is quite good.
This Beiben v3 12 wheel tipper truck price hazardous chemicals version uses the air suspension of the single-axle, three-airbag, six-airbag, and the air suspension height supports adjustment. This configuration is quite advantageous for some dangerous goods transportation industries that often need to be dropped and hung. The Beiben v3 12 wheel tipper truck price can also protect the integrity of the goods when hanging some fragile goods.
Beiben V3 12 Wheel Tipper Truck Price for Sale in Zimbabwe
Beiben V3 12 Wheel Tipper Truck Price for Sale in Zimbabwe
Beiben V3 12 Wheel Tipper Truck Price for Sale in Zimbabwe
Beiben V3 12 Wheel Tipper Truck Price for Sale in Zimbabwe
Nameļ¼ Beiben V3 12 Wheel Tipper Truck Price
Drive form:8X4
Wheelbase:1950+2550+1350mm
Overall Dimension (mm): 10205x2550x3484
Front track: 2042/2042mm
Rear Track: 1878/1878mm
Vehicle weight: 14.77 tons
Rated load: 16.1 tons
Total mass: 31 tons
Approach angle: 17 degrees
Departure angle: 25 degrees
Market segment: Urban construction waste
Engine
Engine model: Weichai WP8.320E61
Number of cylinders: 6
Fuel Type: Diesel
Displacement: 7.8L
Maximum horsepower: 320 horsepower
Maximum output power: 235kW
Maximum torque: 1400N m
Rated speed: 2100rpm
Engine form: in-line six-cylinder, water-cooled, four-stroke, high-pressure common rail, supercharged and intercooled, EGR
Cargo box
L*W*H(mm): 5600x2300x900
Cargo box form: self-unloading
Gearbox
Gearbox Model:Fast 10JSD140T
Forward gear: 10th gear
Number of reverse gears: 2
Fuel tank
Fuel tank capacity: 400L
Chassis
Frame size: 944~850×300×80×8+4mm
Rear axle description: 13T Beiben double reduction axle:
Speed ratio: 4.769
Tire
Tire specification: 11.00R20
Number of tires: 12
