Beiben V3 6x4 Mining Dump Truck

Beiben V3 6x4 Mining Dump Truck

Beiben v3 6x4 mining dump truck using Mercedes-Benz power matching technology and military product testing and testing methods, the power performance of the vehicle is increased by 30%, and the power output is stronger. Under the same load conditions, the fuel consumption is reduced by 15%. The engine  of the Beiben v3 6x4 mining dump truck has large low-speed torque, strong bearing capacity, and a wide range of large torque, enabling the Beiben v3 6x4 mining dump truck to run efficiently under various working conditions, achieving the purpose of multi-pull and fast running.

Beiben V3 6x4 Mining Dump Truck Price for Sale in Philippines

Beiben V3 6x4 Mining Dump Truck Price for Sale in Philippines

Beiben V3 6x4 Mining Dump Truck Price for Sale in Philippines

Beiben 6x4 Mining Dump Truck Specification

Name:  Beiben V3 6x4 Mining Dump Truck Price

Announcement Model: ND3250BD5J7Z08

Drive form: 6X4

Wheelbase: 4400+1450mm

Overall dimension(mm): 9355x2550x3484

Front track: 2004mm

Rear Track: 1874/1874mm

Vehicle weight: 12.5 tons

Rated load: 12.37 tons

Total mass: 25 tons

Approach angle: 17 degrees

Departure angle: 35 degrees

Engine

Engine model: Weichai WP10H375E50

Number of cylinders: 6

Fuel Type: Diesel

Displacement: 9.5L

Maximum output power: 276kW

Maximum torque: 1800N m

Maximum torque speed: 1000-1400rpm

Rated speed: 1900rpm

Engine form: Electronically controlled high pressure common rail + SCR

Cargo box

Overall dimension(mm): 6200x2350x1500

Cargo box form: rear flip self-unloading

Transmission

Gearbox model: Fast 12JSD180T

Forward gear: 12th gear

Number of reverse gears: 2

Fuel tank

Fuel tank capacity: 300L

Chassis

Frame size:

Rear axle description: 13T Beiben double reduction axle

Rear axle allowable load: 18000 (two axles) kg

Speed ​​ratio: 5.263

Number of spring pieces: 10/12

Tire

Tire specifications: 12.00R20 16PR, 11.00R20 18PR, 12R22.5 18PR

Number of tires: 10
