Cheap beiben v3 2534 6x4 tipper truck has good passability: large design values of approach angle and departure angle, and low-speed and high-torque power configuration provide guarantees for beiben v3 2534 6x4 tipper truck to drive in harsh working conditions.
Cheap beiben v3 2534 6x4 tipper truck has high cost performance, large loading capacity, low fuel consumption, and low maintenance costs, and the cheap beiben v3 2534 6x4 tipper truck has significant advantages;
Cheap beiben v3 2534 6x4 tipper truck are easy to maintain. The series of models use engines, transmissions, braking systems, steering systems, and electrical systems that are common to construction machinery and road vehicles. The main wearing parts are highly common.
Cheap Beiben V3 2534 6x4 Tipper Trucks for Sale in Nigeria
Cheap Beiben V3 2534 6x4 Tipper Trucks for Sale in Nigeria
Cheap Beiben V3 2534 6x4 Tipper Trucks for Sale in Nigeria
Name: Beiben V3 2534 6x4 Tipper Trucks for Sale
Drive form: 6X4
Wheelbase: 4400+1450mm
Overall dimension(mm): 9355x2550x3484
Front track: 2004mm
Rear Track: 1874/1874mm
Vehicle weight: 12.5 tons
Rated load: 12.37 tons
Total mass: 25 tons
Approach angle: 17 degrees
Departure angle: 35 degrees
Engine
Engine model: Weichai WP10H375E50
Number of cylinders: 6
Fuel Type: Diesel
Displacement: 9.5L
Maximum output power: 276kW
Maximum torque: 1800N m
Maximum torque speed: 1000-1400rpm
Rated speed: 1900rpm
Engine form: Electronically controlled high pressure common rail + SCR
Cargo box
Overall dimension(mm): 6200x2350x1500
Cargo box form: rear flip self-unloading
Transmission
Gearbox model: Fast 12JSD180T
Forward gear: 12th gear
Number of reverse gears: 2
Fuel tank
Fuel tank capacity: 300L
Chassis
Frame size:
Rear axle description: 13T Beiben double reduction axle
Rear axle allowable load: 18000 (two axles) kg
Speed ratio: 5.263
Number of spring pieces: 10/12
Tire
Tire specifications: 12.00R20 16PR, 11.00R20 18PR, 12R22.5 18PR
Number of tires: 10
