Beiben v3 6x4 dumper truck 10 wheel price use German standard high-strength E500TM material as frame material, which is stamped and formed by a 10,000-ton press, with stronger bearing capacity and fully guaranteed manufacturing quality
Beiben v3 6x4 dumper truck 10 wheel price systematic and integrated design technology of the frame suspension distributes the impact of the road surface reasonably through the middle part (deformation area) of the front-width and rear-narrow variable-section frame and the flexible suspension system to ensure that the wheels, suspension, The synchronous response of the frame of the beiben v3 6x4 dumper truck 10 wheel priceeffectively absorbs the alternating impact load, which not only greatly improves the grounding ability of the wheels of the beiben v3 6x4 dumper truck 10 wheel price, but also greatly improves the reliability and passability of the vehicle.
Beiben V3 6x4 Dumper Truck 10 Wheel Price for Sale in Kenya
Beiben V3 6x4 Dumper Truck 10 Wheel Price for Sale in Kenya
Beiben V3 6x4 Dumper Truck 10 Wheel Price for Sale in Kenya
Name: Beiben V3 6x4 Dumper Truck 10 Wheel Price
Drive form: 6X4
Wheelbase: 4100+1450mm
Overall Dimension(mm): 8825x2550x3430
Front track: 2004mm
Rear Track: 1878/1878mm
Vehicle weight: 12.26 tons
Rated load: 12.61 tons
Total mass: 25 tons
Tonnage class: heavy truck
Approach angle: 17 degrees
Departure angle: 25 degrees
Engine
Engine model: Weichai WP10.350E53
Number of cylinders: 6
Fuel Type: Diesel
Displacement: 9.726L
Emission standard: National V
Maximum horsepower: 350 horsepower
Maximum output power: 257kW
Maximum torque: 1600N m
Maximum torque speed: 1200-1600rpm
Rated speed: 1900rpm
Engine form: Electronically controlled high pressure common rail + SCR
Cargo box
Overall Dimension(mm): 5800x2350x1500
Cargo box form: self-unloading
Transmission
Gearbox model: Fast 10JSD160
Forward gear: 10th gear
Number of reverse gears: 2
Fuel tank
Fuel tank capacity: 300L
Chassis
Frame size:
Rear axle description: Beiben 13 ton double reduction axle
Rear axle allowable load: 18000 (two axles) kg
Speed ratio: 5.263
Number of spring pieces: 10/13
Tire
Tire specification: 11.00R20 18PR, 12.00R20 16PR
Number of tires: 10
