North benz v3 3142 8x4 dump truck price has strong bearing capacity, adopts high-load special axles, specially designed vehicle suspension, high-strength frame assembly, and safe and reliable Hyva hydraulic lifting system
North benz v3 3142 8x4 dump truck price has high safety, It has good anti-rollover performance in the process of unloading and driving on rough mountain roads.The North benz v3 3142 8x4 dump truck price improve driving safety.
North benz v3 3142 8x4 dump truck price has strong power: high-performance engine, high-speed ratio drive axle, and high-torque transmission ensure that the truck smoothly drving on heavy loads.
Brand New North Benz V3 3142 8x4 Dump Truck Price for Sale
Brand New North Benz V3 3142 8x4 Dump Truck Price for Sale
Brand New North Benz V3 3142 8x4 Dump Truck Price for Sale
Name: North Benz V3 3142 8x4 Dump Truck
Drive form: 8X4
Wheelbase: 1950+3400+1450mm
Overall Dimension (mm): 10205x2550x3484
Front track: 2042/2042mm
Rear Track: 1878/1878mm
Vehicle weight: 14.77 tons
Rated load: 16.1 tons
Total mass: 31 tons
Approach angle: 17 degrees
Departure angle: 25 degrees
Engine:
Engine model: Weichai WP10.350E53
Number of cylinders: 6
Fuel Type: Diesel
Displacement: 9.726L
Maximum output power: 257kW
Maximum torque: 1600N m
Maximum torque speed: 1200-1600rpm
Rated speed: 1900rpm
Engine form: Electronically controlled high pressure common rail + SCR
Cargo box
L*W*H (mm): 7200x2350x1180
Cargo box form: self-unloading
Transmission
Gearbox model: Fast 12JS160T
Forward gear: 12th gear
Number of reverse gears: 2
Fuel tank
Fuel tank capacity: Chassis parameters
Frame size:
Rear axle description: 457 single reduction axle
Rear axle allowable load: 18000 (two axles) kg
Speed ratio: 4.769
Number of leaf springs: 12/12/13
Tire
Tire specification: 11.00R20 18PR
Number of tires: 12
