The Beiben ng80 6x4 2534 prime mover adopts a high-efficiency and high-power engine, and the main line transportation power chain constructed by a single-stage reduction axle with a small speed ratio has high transmission efficiency and is not fatigued in long-distance operation.
Beiben ng80 6x4 2534 prime mover selects the golden power chain, carefully selects and pursues perfection. The Beiben ng80 6x4 2534 prime mover adopts a high-efficiency and high-power engine, and a trunk line transportation power chain constructed with a small speed ratio and a single-stage reduction axle, with high transmission efficiency, large torque, automatic shifting without setbacks, and long-distance operation without fatigue, Beiben ng80 6x4 2534 prime mover is especially suitable for trunk line logistics transportation.
Beiben NG80 6X4 2534 Prime Mover for Sale in Kenya
Beiben NG80 6X4 2534 Prime Mover for Sale in Kenya
Beiben NG80 6X4 2534 Prime Mover for Sale in Kenya
name: Beiben NG80 6X4 2534 Prime Mover
Drive form: 6X4
Overall Dimension (mm): 6800x2450x3510
Cab
Cab: High Roof
Number of passengers allowed: 3
Wheelbase: 3200+1350mm
Engine: Weichai WP10.336E40
Gearbox: Fast 12JSD200TA
Rear axle ratio: 4.11
Front Track: 1995mm
Rear track: 1838/1838mm
Vehicle weight: 8.8 tons
Total mass: 25 tons
Total tow mass: 40 tons
Maximum speed: 110km/h
Engine
Engine model: Weichai WP10.336E40
Engine brand: Weichai
Number of cylinders: 6
Fuel Type: Diesel
Cylinder arrangement: in-line
Displacement: 9.726L
Maximum output power: 247kW
Maximum torque: 1500N m
Maximum torque speed: 1300-1600rpm
Rated speed: 1900rpm
Transmission
Gearbox model: Fast 12JSD200TA
Shift mode: manual
Forward gear: 12th gear
Number of reverse gears: 2
Fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 400L
Chassis
Rear axle description: 457 single reduction axle
Rear axle allowable load: 18000kg
Ratio: 4.11
Suspension form: leaf spring
Number of leaf springs: 13/13
Tire
Number of tires: 10
Tire size: 12R22.5
