A beiben 1635 4x2 10m3 tank truck is a tank-shaped transport vehicle used to transport various liquids, liquefied gases and powdered goods, including gasoline, crude oil, various viscous oils, vegetable oils, liquid ammonia, alcohol, water, various acids. Alkali liquid, cement lead oxide powder, etc.
Beiben 1635 4x2 10m3 tank truck has overall load-bearing structure. The body of the beiben 1635 4x2 10m3 tank truck is composed of two parts: the tank body and the bottom frame.
The tank body of the beiben 1635 4x2 10m3 tank truck is a horizontal cylinder structure, and the cylinder body part is welded by the upper plate, the bottom plate and the end plate.
Because the tank itself has great rigidity, the weight of the liquid in the tank is mainly borne by the tank, and then transmitted to the bogie through the bracket and the bolster, so the bottom frame of the beiben 1635 4x2 10m3 tank truck mainly bears the horizontal longitudinal traction impact force.
Beiben 1635 4x2 10m3 Tank Truck for Sale Price in Kenya Mombasa
Beiben 1635 4x2 10m3 Tank Truck for Sale Price in Kenya Mombasa
Beiben 1635 4x2 10m3 Tank Truck for Sale Price in Kenya Mombasa
Name：Beiben 1635 4x2 10m3 Tank Truck
Traction: type 4X2
Driving type: LHD/RHD
Dimension(Lx W xH):（unloaded）10576×2500×3430
Wheel base(mm): 5050+1450
Max speed:（km/h）90
Curb weight（kg）: 12000
Loading Weight（kg）:25,000
Engine
Model:WD615.340
water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection With the exhaust valve brake, EGR (gas exhausted recycling), deisel engine
Displacement（L）:9.726/Diesel
Bore X stroke(mm) :126/130
Max power（kw/rpm）:247/2200 (340hp)
Max torque（Nm/rpm）:1350/1300-1600
Emission : EURO II
Fuel tanker（L）: 400L steel fuel tanker
Clutch
Model: 430 Diaphragm type
Gearbox
Model 9JS150 (Fuller) mechanism, 9gears, 1reverse gear
Brake system
Service brake Brake gap can be adjusted automatically, double circulation air brake system
Assistant brake Engine exhaust brake
Park brake Potential springs pressing on middle and rear wheels
Steering system
Model: ZF8098
Frame Fish belly, shape, variable width, variable sections, side beam structure
Front axle (Mercedes Benz Technology) 7.5T Double-shoe pneumatic brake, non-driving steering axle
Middle and Rear axle (Mercedes Benz Technology) 13T Double-shoe pneumatic brake, casting, double reduction driving axles with inter-wheel & inter-axles differential locks
Tyre: 12.00R20 Radial tyre Number of tyre:10+1 spare
Electrical system
Battery : 2X12V/135Ah
Generator: 28V-35A
Starter: 5.4Kw/24V
Cab
Cabin, single sleeper with air-conditioner
Full steel skeleton structure, covered with double layer steel plate;
Can be tipped forwardly;
Tank
Tank capacity: 1,0000 liters
Thickness of the tanker body: cthe thickness of the shell is 5mm approx
