The beiben v3et 2540 6x4 track pays attention to driving comfort, with a beautiful and fashionable appearance. The space layout and utilization rate of the driving position are quite high, and the floor of the beiben v3et 2540 6x4 track is also very flat, which is very comfortable and user-friendly. This beiben v3et 2540 6x4 track has the blessing of the high-top row half seat bag, and the length of the seat bag cushion also ensures that the last row of guests has sufficient support for their thighs.
Beiben Track | Beiben V3ET 2540 6x4 Track for Sale
Beiben Track | Beiben V3ET 2540 6x4 Track for Sale
Beiben Track | Beiben V3ET 2540 6x4 Track for Sale
Name: Beiben V3ET 2540 6x4 Track
Drive model: 6X4
Cab
Cab: High Roof
Cab Suspension: Four-point airbag suspension
Number of passengers allowed: 3
Wheelbase: 3300+1350mm
Engine: Weichai WP12.460E50
Gearbox: Fast 12JSDX220TA-B
Rear axle ratio: 3.7
Body length: 6.905 meters
Body width: 2.5 meters
Body height: 3.97 meters
Front track: 2045mm
Rear track: 1850/1850mm
Vehicle weight: 8.8 tons
Total mass: 25 tons
Total tow mass: 40 tons
Maximum speed: 110km/h
Engine
Engine model: Weichai WP12.460E50
Engine brand: Weichai
Number of cylinders: 6
Fuel Type: Diesel
Cylinder arrangement: in-line
Displacement: 11.596L
Maximum output power: 338kW
Maximum torque: 2110N m
Maximum torque speed: 1000-1400rpm
Rated speed: 1900rpm
Transmission
Gearbox model: Fast 12JSDX220TA-B
Shift mode: manual
Forward gear: 12th gear
Number of reverse gears: 2
Fuel tank
Fuel tank material: aluminum alloy
Fuel tank capacity: 400L
Chassis
Frame size: 284×80×8mm
Rear axle description: 440A single reduction axle
Front axle allowable load: 7000kg
Rear axle allowable load: 18000 (two axles) kg
Speed ratio: 3.7
Hanging form:
Number of spring pieces: 2/3
Saddle: 90#
Tire
Number of tires: 10
Tire specification: 12R22.5 18PR
