There are 4 Vice- beam to suport the bottom platform of 30 cubic 3 axle hydraulic tipper trailer by one side ,the whole 30 cubic 3 axle hydraulic tipper trailer is total 8 vice beam more stronger and better bearing capacity.
The diameter is 60# 4 rotation pin of 30 cubic 3 axle hydraulic tipper trailer，more stronger and wear-resistant and long service time.
New Tipper Price in Kenya | 30 Cubic 3 Axle Hydraulic Tipper Trailer for Sale Price
New Tipper Price in Kenya | 30 Cubic 3 Axle Hydraulic Tipper Trailer for Sale Price
New Tipper Price in Kenya | 30 Cubic 3 Axle Hydraulic Tipper Trailer for Sale Price
Dimension: 8112mmx2500mm x3482mm ( inside dimension )
Total volume: 30 cubic
Side wall thickness: 4 - 6mm
End plate: 8mm
Lifting System: Full set of HYVA lifting cylinder
Axle: 3 Axle, 13T, FUWA
Rim: 8.0-20 or 9.00-20
Tire: 12R22.5
Suspension: Mechanical suspension
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Landing gear: JOST brand
